USN1152 1.5 HP NorthStar Pool Pump Motor 56J Frame C-Face 115/230V

It is important to know that pool pump motors are not manufactured by the pump manufacturer; the motor will usually be manufactured by AO Smith, Magnetek or Centurion. Your pump's motor should have a label or faceplate on it which includes the information you need to replace your pump motor. The most important categories to note will be the horsepower (hp), motor frame (fr), voltage and service factor (sf). Some labels will provide you with a model number and it will usually be listed as CR or CAT.

When replacing your pool pump motor you should always replace the shaft seal as well. The shaft seal is a 2 part piece made of rubber, metal and ceramic and keeps water from entering the pump motor. It is located near the impeller at the end of the motor shaft. Shaft seals vary between pumps so be sure to order the appropriate shaft seal for your pump.

More Information
Delivery Time 2-5 Business Days
Manufacturer AO Smith
Technical Specs

Horsepower: 1.5 HP
Service Factor: 1.25
Voltage: 115/208-230 Volt
Amperage: 15.6/8.5-7.8
RPM: Single speed - 3450 RPM
Rotation: CCW at Pump End
Max Temp: 50 Degrees Celsius ambient

Works with the following pumps:
Hayward Super Pump
Hayward Super II
Hayward Max-Flo
Hayward NorthStar
Jandy Stealth
Jandy Plus HP
Jandy HHP
Jacuzzi Magnum

SKU AOS-60-6009
Manufacturer Part # USN1152
Product Features
  • 1.5 HP - Up Rated
  • For Hayward NorthStar Pumps
  • Service Factor: 1.25
  • 56J Frame
  • Threaded Shaft
  • 115 / 208-230 Volt
  • 15.6 / 8.5-7.8 amps
  • Capacitor Start
  • Automatic Overload Protection
  • Non-Reversible CCW
  • Stainless Steel Shaft
  • Cross References: SP1610-Z-1-MNS, SPX1610Z1MNS, SP1610Z1MNS, 7-193685-02, EUSN1152, SP1610Z1MNSC
In stock
$428.99
