Aqua-Flo Flo-Master FMCP 1.5 HP 2 Speed 115V Spa Pump 02615000-1010

Aqua-Flo 02615000-1010 Flo-Master CP Series Pumps are perfect for spas and hot tubs with several jets since they often require a greater output. The outstanding flow rates of the Flo-Master allow the pump to run at a lower horsepower to do the same job of higher horsepower pumps. Using less horsepower means a lower operating cost and more money in your pocket!

The Aqua-Flo Flo-Master FMCP Pump has a center discharge on the top of the pump and the FMHP Pump has an side or offset discharge. Flo-Master Pumps come complete with quick release compression fittings which makes installation and maintenance very simple. The upgraded shaft seal and high performance impeller help to provide a high level of performance in any condition.

Replaces the following pump models:
02615500-2 (Turned To 3' OClock)

More Information
Delivery Time 2-5 Business Days
Manufacturer Aqua-Flo
Technical Specs

Suction Connection Size: 1-1/2"
Connection Type: FPT, MBT
Discharge Connection Size: 1-1/2"
Connection Type: FPT, MBT
Operational Horsepower: 1.5 HP
Total Horsepower: 2 HP
Motor Speed: 2-Speed
Motor Frame: 48 Frame
Motor Amperage: 14.4A/5.5A
Motor Voltage: 115V
Model: FMCP
Impeller Number: 91693651

Product Documentation
SKU AQF-10-382
Manufacturer Part # 02615000-1010
Product Features
  • AquaFlo part number FMCP 02615000-1010
  • FMCP - Center Discharge
  • Ideal for larger, multi-jet tubs
  • Quick release compression fittings
  • Easy installation or maintenance
  • Compact, unitized, single spring mechanical seal
  • Maximum durability and performance
  • High-performance impeller
  • Povides flow rates that exceed all tested competition
  • Drip proof, cool running seal eliminates seal burnout
  • Stainless steel fasteners
  • Unions are included
  • 1.5" Inlet and outlet plumbing connections
  • Inside Ports Measure 1-7/8"
  • Outside Threads Measure 2-7/16"
  • Unions are included
  • Operational Horsepower: 1.5 HP
  • Total Horsepower Rating: 2 HP
  • 115 Volt
  • 2 Speed
